EC-9500 Conductivity Controller
Industrial online conductivity/resistivity measurement with ARM MCU.
View Details
This instrument is a panel instrument for on-line monitoring of industrial process conductivity. Range switch over and constant check can both be freely set and adjusted through the operation component on the rear panel; unique signal collecting and processing technology and special thick film circuit are adopted to make measurement accurate and operation stable; there are also other features such as linearized data, automatic temperature compensation, not subject to the length change of cable and maintenance-free. It's an ideal auxiliary instrument of various types of small pure water equipment.
| Model | EC-8850 |
|---|---|
| Name | EC-8850 Conductivity/Resistivity Controller |
| Measuring Range | Conductivity: 0.055-400,000uS; Resistivity: 10kΩ-18.25MΩ; TDS: 0.023-200,000ppm |
| Displaying Mode | LCD display with backlight, LCD 2x16 bit |
| Accuracy | 1.0% (FS) |
| Current Output Signal | 4-20mA, isolated, transportable |
| Refresh Rate | 3S |
| Current Accuracy | ±0.03mA @25℃, 24V |
| Control Output Signals | Hi/Lo/off (normally open contact) |
| Pulse Output Signal | Pulse modes (maximum pulse rate: 400p/m), RS485 communication output signal |
| Power Supply | 18-36V DC |
| Communication Output | RS485, BAUD RATE: 2400, 4800, 9600 |
